High voltage power cable XLPE cable manufacturer 132kV cable

FOB Reference Price:Get Latest Price
$3.60 - $150.00 / Meter | 100 Meter/Meters (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
Owire
Model Number:
vv, VV / VLV
Type:
High Voltage
Application:
Construction
Conductor Material:
Copper, Copper Clad Aluminum, copper,aluminium alloy
Jacket:
PE
Insulation Material:
PVC
Core:
3 Cores
Rated voltage:
26/35kV
Color:
Black
Product name:
Steel Armored Cable
Certification:
ISO9001
product name:
High voltage power cable XLPE cable manufacturer 132kV cable
Supply Ability
Supply Ability:
20000 Meter/Meters per Week
Packaging & Delivery
Packaging Details
1.In rolls or in wooden drum.
2.In export wooden pallet .
3.as per customer's requirements.
Port
Shenzhen/Guangzhou/Hongkong

High voltage power cable XLPE cable manufacturer 132kV cable



Product Description



1.Application :



Used for indoor & outdoor laying,The Cable can bear a certain laying traction,but can't bear the mechanical force from outide.Single core cable can't be allowed to lay in the magnetic pipe . The Cable is used for fixed laying in the rated voltage (U0/U)0.6/1KV,3.6/6KV & below for power transmission.



2.Product implementation standard:



GB/T12706-2002 Rated Voltage 1KV(uM=1.2KV) to 35KV(uM=40.5Kv) insulation electrical power & auxilary IEC60502-1997 Rated voltage 1-30kV Insulation electrical power cable & auxiliaries.



3.Operational performances:



   (1)Working temperature:



   The Max.conductor working temperature: 70 Centigrade    Conductor short circuit temperature : highest temperature not more than 160 , the longest time not more than 5 seconds.



The min.bending radius of cable installation :



Table 1 :

Item

Single core Power Cable

3 Cores Electrical Power Cable

No Armour

With Armour

No Armour

With Armour

The Min.bending radius of cable installation

20D

15D

15D

12D

The min.bending radius near connecting box & terminal cable

15D

12D

12D

10D

Note : "D" refers to outside diameter of electrical power cable.



(2)Installation laying temperature :

Cable installation laying temperature not less than 0 Cable current-carrying capacity laying mode & basic parameters: Air laying: enviromental temperature : 40 Soil laying: enviromental temperature : 25 Soil Thermal resistance coefficient : 1.0.m/W Cable laying arrangments:

Single core calbe arrangment :Flat type. (adjacent space equals to cable outside diameter);
